JCB 25Z-1 Mini Excavator
Say goodbye to daily maintenance headaches and cramped job sites. The JCB 25Z-1 is engineered to drastically reduce your cost of ownership by featuring extended 500-hour greasing intervals and an efficient Kohler engine that completely eliminates the need for expensive exhaust after-treatment. Thanks to a true zero tailswing design, your operators can work confidently flush against walls and fences without the risk of rear-swing property damage. Packing over 5,000 lbf of bucket breakout force into a highly towable 5,622-pound frame, it’s the ultimate zero-compromise solution for residential landscaping and tight-access utility work.
Specifications
| Operator Protection | ROPS/TOPS / Lift Overload Alarms / 2GO Hydraulic Isolation |
| Tail Swing Type | True Zero Tailswing |
| Operating Weight | 5622.0 lb |
| Overall Width | 59.0 in |
| Overall Height | 97.0 in |
| Overall Length | 165.0 in |
| Horsepower | 24.7 hp |
| Engine Manufacturer | Kohler |
| Emissions Tier | EPA Tier 4 Final (No Engine After-Treatment) |
| Fuel Tank Capacity | 7.9 gal |
| Maximum Digging Depth | 118.0 in |
| Maximum Reach at Ground Level | 171.5 in |
| Maximum Dumping Height | 119.3 in |
| Bucket Breakout Force | 5015.0 lbf |
| Stick Digging Force - Standard | 3664.0 lbf |
| Blade Size (H x W) | 12.2 x 61.0 in |
| Arm Configuration | Standard |
| Auxiliary Circuit Flow | 12.7 gal/min |
| Track Shoe Type | Rubber |
| Ground Pressure | 4.55 psi |
Current Promotions
Current promotions can save you money. We offer promotions that may include Low finance rates, cash back, bonus attachments and more. Check out our current promotional offers to see what may apply to your next equipment purchase.
Businesses and individuals are eligible for rebates up to $2,000 when purchasing a New JCB electric 19C-1E and/or 1TE model through CleanBC!
Dig up the savings on a new JCB Mini Excavator with 0% financing for up to 60 months on select models.
Specifications and images may vary in accuracy.
