JCB 4TS-8T Teleskid Compact Track Loader
Command maximum reach and power with the JCB 4TS-8T Teleskid, featuring an exclusive telescopic boom that stretches 8 feet forward and digs 3 feet below grade. Powered by a 109-horsepower engine, this 13,000-pound compact track loader transitions effortlessly from a massive 4,000-pound retracted operating capacity to a 1,878-pound extended capacity.
The 4TS-8T clears high-sided trucks easily with a towering 180-inch maximum hinge pin height and tears into dense material with 7,919 pounds of bucket breakout force. Supported by a standard 24-gpm auxiliary flow that scales to 43 gpm for intense attachments, operators maintain total control from a side-entry cab equipped with switchable joystick patterns.
Specifications
| Operator Protection | Full ROPS and FOPS |
| Control Type | Switchable ISO/H-Pattern Joysticks |
| Operating Weight | 13000.0 lbs |
| Length with Bucket | 158.0 in |
| Width with Bucket | 75.0 in |
| Height to Top of Cab | 78.0 in |
| Engine Manufacturer | JCB |
| Engine Model | EcoMAX TCAE-81 |
| Gross Horsepower | 109.0 hp |
| Emissions Tier | Tier 4 Final |
| Fuel Tank Capacity | 27.3 gal |
| Rated Operating Capacity (ROC) | 3,999 (retracted) / 1,878 (extended) lbs |
| Tipping Load | 11,426 (retracted) / 5,366 (extended) lbs |
| Lift Path | Telescopic |
| Height to Hinge Pin | 142.0 (retracted) / 180.0 (extended) in |
| Bucket Breakout Force | 7919.0 lbs |
| Standard Auxiliary Flow | 24.0 gal/min |
| High Auxiliary Flow | 42.5 gal/min |
| Transmission | 2-Speed |
| Travel Speed (low) | 6.2 mph |
| Travel Speed (high) | 7.8 mph |
