New Equipment
Bobcat G15S-5 IC Pneumatic Forklift
Improve productivity and lower operation costs with the Bobcat G15S-5 5-series IC Pneumatic forklift. This machine is complete with quality safety features including an operator sensing system and ergonomic controls in the spacious operator compartment. Utilize its load capacity of 3,000 lbs meet your unique worksite needs and increase efficiency on the job.
Specifications
| Brakes | Wet Disc |
| Relief Pressure Hyd | 2552.0 |
| Lowered Overall Height | 86.0 in |
| Mast | 3-Stage |
| Maximum Fork Height | 129.9 in |
| Standard Mast: Free Lift | 5.3 in |
| Steering | Hydrostatic |
| Number of Speeds | 1/1 |
| Transmission | Powershift |
| Outside Turning Radius | 77.8 in |
| Center of Wheelbase | 5.9 in |
| Fork Size (T x W x L) | 1.4 X 4 X 41 in |
| Front Overhang | 15.5 in |
| Height to Top Overhead Guard | 85.4 in |
| Maximum Fork Spread | 35.6 in |
| Minimum Aisle Right Ang Stack | 92.9 in |
| Overall Length | 85.4 in |
| Overall Width | 42.1 in |
| Tread (Front/Rear) | 35.0/35.8 |
| Wheelbase | 55.1 in |
| Lift Capacity | 3000.0 lbs |
| Max Fork Height Rated Capacity | 157.0 in |
| Maximum Drawbar Pull | 3086.0 lbs |
| Travel Speed Loaded | 11.2 mph |
| Gradeability Loaded @ 1 mph | 37.0 percent |
| Load Center | 19.7 in |
| Cylinders/Displacement | 4/121.8 |
| Engine Manufacturer | Mitsubishi |
| Engine Model | G420FE |
| Horsepower | 47.0 hp |
| Power Mode | LPG |
| Torque @ RPM | 113.0 ft-lb |
Current Promotions
Current promotions can save you money. We offer promotions that may include Low finance rates, cash back, bonus attachments and more. Check out our current promotional offers to see what may apply to your next equipment purchase.
Specifications and images may vary in accuracy.
Data Powered By EquipmentWatch
