Clark CGC40 IC Cushion Forklift
The CLARK CGC40 is a heavy-duty IC cushion forklift made for tight, smooth-floor spaces, such as manufacturing cells, building-materials handling, paper rolls, cargo and distribution docks. It’s rated at 8,000 lb, giving solid capacity in a compact footprint. Turning is tight with an outside turning radius of 89.4-in, and the standard 2-stage mast up to 169-in. 3-stage masts are also available. The mix of cushion tires, short radius, and flexible mast options makes the CGC40 a strong fit wherever heavy loads meet limited space.
This forklift incorporates Clark's history in ergonomics, power, safety, durability, and performance to offer a machine that is high performance and offers great value to your business.
Specifications
| Brakes | Power Assist Disc |
| Mast | 3-Stage |
| Standard Mast: Free Lift | 6.5 in |
| Maximum Fork Height | 188.0 in |
| Lowered Overall Height | 89.0 in |
| Steering | Hydrostatic |
| Number of Speeds | 1F/1R |
| Transmission | Powershift |
| Front Overhang | 17.3 in |
| Maximum Fork Spread | 40.0 in |
| Minimum Aisle Right Ang Stack | 106.7 in |
| Wheelbase | 61.8 in |
| Tread (Front/Rear) | 41.8/44 |
| Overall Width | 50.8 in |
| Overall Length | 96.0 in |
| Fork Size (T x W x L) | 2 X 5 X 42 in |
| Height to Top Overhead Guard | 87.2 in |
| Center of Wheelbase | 6.1 in |
| Drive Tire Size | 22 x 9 x 16 |
| Steer Tire Size | 18 x 6 x 12.12 |
| Lift Capacity | 8000.0 lbs |
| Gradeability Loaded @ 1 mph | 27.1 percent |
| Load Center | 24.0 in |
| Maximum Drawbar Pull | 5250.0 lbs |
| Travel Speed Loaded | 12.2 mph |
| Max Fork Height Rated Capacity | 198.0 in |
| Cylinders/Displacement | 262.0 |
| Engine Manufacturer | GM |
| Engine | Vortec 4300LT |
| Power Mode | LPG |
| Horsepower | 93.0 hp |
| Torque @ RPM | 235.0 ft-lb |
