Bobcat G15S-5 IC Pneumatic Forklift
Improve productivity and lower operation costs with the Bobcat G15S-5 5-series IC Pneumatic forklift. This machine is complete with quality safety features including an operator sensing system and ergonomic controls in the spacious operator compartment. Utilize its load capacity of 3,000 lbs meet your unique worksite needs and increase efficiency on the job.
Specifications
| Brakes | Wet Disc |
| Power Mode | LPG |
| Torque @ RPM | 113.0 ft-lb |
| Engine | G420FE |
| Horsepower | 47.0 hp |
| Engine Manufacturer | Mitsubishi |
| Cylinders/Displacement | 4/121.8 |
| Relief Pressure Hyd | 2552.0 |
| Lowered Overall Height | 86.0 in |
| Standard Mast: Free Lift | 5.3 in |
| Maximum Fork Height | 129.9 in |
| Mast | 3-Stage |
| Steering | Hydrostatic |
| Transmission | Powershift |
| Number of Speeds | 1/1 |
| Fork Size (T x W x L) | 1.4 X 4 X 41 in |
| Front Overhang | 15.5 in |
| Height to Top Overhead Guard | 85.4 in |
| Maximum Fork Spread | 35.6 in |
| Minimum Aisle Right Ang Stack | 92.9 in |
| Overall Length | 85.4 in |
| Overall Width | 42.1 in |
| Tread (Front/Rear) | 35.0/35.8 |
| Wheelbase | 55.1 in |
| Center of Wheelbase | 5.9 in |
| Steer Tire Size | 5.00 x 8-10 |
| Drive Tire Size | 6.50 x 10-12 |
| Lift Capacity | 3000.0 lbs |
| Maximum Drawbar Pull | 3086.0 lbs |
| Load Center | 19.7 in |
| Travel Speed Loaded | 11.2 mph |
| Gradeability Loaded @ 1 mph | 37.0 percent |
| Max Fork Height Rated Capacity | 157.0 in |
