Linde HT120 IC Pneumatic Forklift
Transport heavy loads with cost efficiency. The HT120 IC trucks has a lift capacity of 24,000 lbs which lets you knock out the toughest applications. Thanks to its modern diesel engine, transmission, and hydrodynamic drive, this machine provides strong handling performance, ideal for transport over long distances. Operators benefit from built in safety features such as excellent 360 visibility and comfort components to increase efficiency on the job. Reduce service time and increase handling capacity – the Linde HT120 IC truck can deliver superior results to your business.
Specifications
| Brakes | Wet Disc |
| Horsepower | 190.4 hp |
| Engine Manufacturer | Cummins |
| Engine | QSB6.7 |
| Cylinders/Displacement | 6/409 |
| Power Mode | Diesel |
| Relief Pressure Hyd | 3626.0 |
| Lowered Overall Height | 131.5 in |
| Mast | 2-Stage |
| Maximum Fork Height | 157.5 in |
| Standard Mast: Free Lift | 6.0 in |
| Steering | Hydrostatic |
| Transmission | Hydrostatic |
| Number of Speeds | Variable |
| Overall Width | 99.8 in |
| Wheelbase | 116.5 in |
| Overall Length | 180.2 in |
| Tread (Front/Rear) | 72.6/69.6 |
| Center of Wheelbase | 10.0 in |
| Fork Size (T x W x L) | 2.75 X 7 X 45 in |
| Front Overhang | 33.5 in |
| Height to Top Overhead Guard | 114.4 in |
| Maximum Fork Spread | 93.3 in |
| Outside Turn Radius | 157.2 in |
| Steer Tire Size | 10.00 X 20/16PR |
| Drive Tire Size | 10.00 X 20/16PR |
| Gradeability Loaded @ 1 mph | 22.5 percent |
| Travel Speed Loaded | 17.5 mph |
| Maximum Drawbar Pull | 15602.0 lbs |
| Max Fork Height Rated Capacity | 170.5 in |
| Lowering Spd (Loaded/Unloaded) | 106.3/106.3 |
| Load Center | 24.0 in |
| Lifting Spd (Loaded/Unloaded) | 106.3/110.2 |
| Capacity | 26000.0 lbs |
