JCB 437 Wheel Loader

Request a Quote

Specifications

Boom, Bucket, Loader, Platform, and Stick

Bucket Capacity	2.4 cu yd
Bucket Type	General Purpose

Dimensions

Operating Weight

31967.0 lbs

Operator Environment

Operator Protection

ROPS/FOPS

Weights & Dimensions

Height to Top of Cab	132.0 in
Height to Hinge Pin	158.3 in
Overall Width	102.3 in
Overall Length W/Bucket	287.4 in
Overall Height	158.3 in
Overall Length	287.4 in
Bucket Rollback (Full Height)	58.0 degrees
Dump Height	110.0 in
Dump Reach @ Full Height	43.9 in
Height To Top Of Exhaust	122.4 in
Maximum Operating Height	158.3 in
Maximum Operating Weight	39242.3 lbs
Overall Height (Bucket Raised)	158.3 in

None

Horsepower	161.0 hp
Engine Manufacturer	Cummins
Engine Model	QSB
Power Mode	Diesel

Current Promotions

Current promotions can save you money. We offer promotions that may include Low finance rates, cash back, bonus attachments and more. Check out our current promotional offers to see what may apply to your next equipment purchase.

Enjoy 0% Financing for 60 Months on Select JCB Equipment

Get a bumper deal on a new JCB Compact Excavator or Compact Wheel Loader with 0% financing for up to 60 months.

Expires: March 31, 2026

PROMO

Specifications and images may vary in accuracy.

Data Powered By EquipmentWatch
