Bobcat TL623 Telehandler
The Bobcat TL623 is a compact telehandler built for jobs that need more lifting capacity and reach without moving into a much larger machine. It delivers a 6,000 lb maximum lift capacity, reaches about 22 ft high and provides more than 13 ft of forward reach. With 4,400 lb of capacity available at full height and 2,300 lb at full reach, it gives operators useful load-handling capability for construction, agriculture, landscaping and yard work.
A 74 hp turbocharged Bobcat Tier 4 diesel engine powers the TL623, with two-speed hydrostatic travel reaching up to 18.3 mph. Four steering modes help with positioning in tight work areas, while standard automatic ride control reduces load movement when traveling over uneven ground. The Power Bob-Tach mounting system and 21.1 gpm auxiliary hydraulic flow allow the machine to work with forks, buckets, grapples and other approved attachments, giving it more versatility than a conventional lift-only telehandler.
Current Promotions
Current promotions can save you money. We offer promotions that may include Low finance rates, cash back, bonus attachments and more. Check out our current promotional offers to see what may apply to your next equipment purchase.
Bobcat TL623 Specifications
| Operator Protection | ROPS / FOPS |
| Weight | 12191.0 lbs |
| Overall Width | 82.7 in |
| Overall Height | 84.3 in |
| Overall Length to Carriage | 196.7 in |
| Wheelbase | 111.0 in |
| Ground Clearance | 10.4 in |
| Engine Manufacturer | Bobcat |
| Engine Model | D34 |
| Horsepower | 74.0 hp |
| Emissions Tier | Tier 4 |
| Fuel Tank Capacity | 30.4 gal |
| Power Source | Diesel |
| Max Lift Capacity | 600.0 lbs |
| Max Lift Height | 264.0 in |
| Lift Capacity at Max Height | 4400.0 lbs |
| Max Forward Reach | 159.8 in |
| Lift Capacity at Max Reach | 2300.0 lbs |
| Max Travel Speed | 18.3 mph |
| Auxiliary Hydraulic Flow | 21.1 gpm |
| Steering Modes | Front Wheel, All Wheel, Crab, Semi-Crab |
| Tire Size | 405/70-20 in |
Specifications and images may vary in accuracy.
